--- 3 retpahC Instrument Setup
3 - Instrument Setup
Unpacking and Repacking
Safety Precautions
Use safe lifting practices when moving the QS12. At least two people are required to safely move the
instrument.
QS12 has a high centre of gravity and care should be taken when moving.
Do not tip the QS12 more than 30° from the upright position.
After moving the QS12, wait at least 8 hours before switching on to allow the refrigerant to settle -
failure to do so may cause damage to the unit.
N
ote
e carefully stored for use in any future instrument shipment.
U
npacking Procedure
General Information:
• Inspect the packaging, if it is damaged and/or the contents do not match the supplied packing list, inform your
• Ensure that these Instructions are retained for future use.
•
foam
spacers inside the container. A wooden cover protects the top of the instrument.
• In unpacking be aware of the weight (143 Kg/315.2 lbs) of the instrument, at least two people are required to
safetly move the instrument.
Unpacking the Instrument:
• Cut through the three packing straps and remove
the packing.
• Remove the upper wooden co
•
e hinges of the upper wooden cover are secured
with tape.
• Remove this tape.
•
2).
•
Remove the upper and lower supporting fo
1.3, 1.4, 1.5, 1.6) from the QS12.
Fig 1
Avantik representative.
