--- 3 retpahC Instrument Setup
The installation site must also be free from:
• Draught by open doors or by air conditioning
systems.
• Direct exposure to sunlight into the cooling
chamber.
Note
Both measures reduce the formation of frost and therefore
result in more favourable work conditions. High air
moisture as well as high ambient temperatures reduce the
maximum performance of the instrument.
• To stabilize the complete unit, tighten the sc
2a) (item 1) by using the attached tool.
• Install the separate, packed handwheel handle.
Fig 2a
• Install the separately packed handwheel handle
on the handwheel with the attached screw by
means of the Allan key.
Fig 2b
Repacking the Instrument
To repack the instrument, follow the above instructions in reverse order.
