Station port Cable pair
9 Red Brown
10 Red Slate
11 Black Blue
12 Black Orange
13 Black Green
14 Black Brown
15 Black Slate
16 Yellow Blue
17 Yellow Orange
18 Yellow Green
19 Yellow Brown
20 Yellow Slate
21 Violet Blue
22 Violet Orange
23 Violet Green
24 Violet Brown
OPEN Violet Slate
Related links
The front panel of the Avaya MM717 media module on page 123
MM717 LEDs
Table 22: MM717 LEDs
LED
Name Color Indication
ALM Alarm Red The module type is not the type configured in the MSG
for the slot
TST Test Green Either a test is being performed on the module via the
server, or the module is performing a self-test upon
initial insertion
ACT Activity Yellow A device connected to the module is in use
Related links
The front panel of the Avaya MM717 media module on page 123
The front panel of the Avaya MM720 media module
The MM720 ISDN BRI media module contains eight 4-wire S/T ISDN BRI ports. These ports
interface to the central office at the ISDN T reference point.
Front panel description
