Data and voice device connections
There are various possible ways of connecting different devices. See your planning documentation
for any topology requirements to connect specific devices to specific ports. As you connect devices,
keep a record of the slots and ports into which specific devices are connected. You will need this
information when configuring the Branch Gateway.
Related links
Connecting devices on page 43
Switch or network data port connections on page 44
IP telephone connections on page 44
ISDN BRI station connections on page 45
Connecting an analog telephone on page 46
Connecting a DCP telephone to an MM712 or MM717 media module on page 48
Connecting an analog trunk on page 49
Connecting an analog DID trunk on page 49
Connecting an E1/T1 trunk on page 49
Connecting an ISDN BRI trunk on page 50
Connecting devices to the MM717 and MM716 media modules on page 50
Switch or network data port connections
You can connect one or more LAN switches to either of the ETH LAN ports on the front panel.
Related links
Data and voice device connections on page 44
IP telephone connections
Note:
For a full list of supported phones, see Appendix B, Supported Avaya telephones in Overview
for the Avaya G430.
Connect the IP telephone to an external Ethernet switch that has connectivity with the Avaya Branch
Gateway G430. The IP phone can powered either by the switch or by its own power supply.
Related links
Data and voice device connections on page 44
Connecting the telephone to the Branch Gateway on page 44
Connecting the telephone to the Branch Gateway
Procedure
1. Wire a telephone to a port on the switch connected to the Branch Gateway LAN port.
Connecting devices
February 2017 Installation and Upgrades for the Avaya Branch Gateway G430 44
