Description Value
Power rating 90V to 264V AC, 48 to 63 Hz
BTU 800 BTU/h
Max current 2.4 A
Related links
Technical specifications on page 128
EM200 specifications
The following table of technical specifications provides detailed information on the physical
dimensions and tolerances of the EM200 expansion module:
Table 26: EM200 specifications
Description Value
Height 2.62 in. (66.5 mm)
Width 19 in. (482.6 mm)
Depth 12.8 in. (325 mm)
Weight of empty chassis under 11 pounds (under 5 kg)
Weight of chassis with media modules
and brackets
13 pounds (6 kg)
Ambient working temperature 32° to 104°F (0° to 40°C)
Operation altitude up to 10,000 ft. (3000 m)
Front Clearance 12 in. (30 cm)
Rear Clearance 18 in. (45 cm)
Humidity 10-90% relative humidity, non-condensing
Power rating 90V-264V AC, 48-62 Hz
BTU 430 BTU/h
Max current 3 A
Related links
Technical specifications on page 128
Power cord specifications
Following are specifications for power cords suitable for use with the gateway.
For North America:
The cordset must be UL Listed/CSA Certified, 16 AWG, 3-conductor (3rd wire ground), type SJT.
One end is to be terminated to an IEC 60320, sheet C13 type connector rated 10A, 250V. The other
Technical specifications
February 2017 Installation and Upgrades for the Avaya Branch Gateway G430 129
