Connecting an analog trunk

Procedure

Connect the trunk to one of the following ports:

• Any universal analog port on an MM711 media module

• One of the ports marked TRUNK on an MM714 or MM714B media module

Related links

Data and voice device connections on page 44

Connecting an analog DID trunk

Procedure

Connect the trunk to one of the following ports

• Any universal analog port on an MM711 media module

• Any analog line port on a punch down block connected to an MM716 media module.

To connect the MM716 media module to a punch down block to enable trunk connection,

Connecting devices to the MM717 and MM716 media modules on page 50.

• One of the ports marked Line on an MM714 or MM714B media module

• The TRUNK port on the Branch Gateway front panel.

Note:

The TRUNK analog telephone port on the Branch Gateway front panel forms a mechanical

analog relay with the LINE port next to it. See

the figure on page 29. This relay can be

configured to provide emergency transferred telephone service in the case of a power outage

or disconnection from an external server. During an emergency situation, all incoming calls

on the trunk are directed to the telephone plugged into the LINE port. Conversely, the

telephone plugged into the LINE port can use the trunk during an emergency situation to

make outgoing calls.
