Chapter 8: Upgrading and replacing Field
Replaceable Units
Field Replaceable Unit upgrades and replacements
You can add or remove VoIP modules, the fan tray, or a power supply unit. You can add or replace
a VoIP module, as well as add or remove components of the upgrade memory kit. Refer to
Equipment list for ordering information.
Note:
The G430 v1 has an on board MP20. However, if an MP120 is installed on G430 v1, the on
board MP20 will be disabled. G430 v2 has no on board media processor but a pre-installed
MP120 module. You can identify the G430 version by determining either the C/S number on the
label or the comcode number.
Related links
Inserting or removing an MP10, MP20, MP80, or MP120 VoIP module on page 74
Installing the upgrade memory kit on page 80
Inserting or removing an MP10, MP20, MP80, or MP120 VoIP
module
About this task
G430 v1 has one on-board VoIP module providing 25 VoIP channels for G.711 and G.726 and 20
channels for G.729, and an additional slot for the optional insertion of an MP10, MP20, MP80, or
MP120 VoIP module. If an MP120 is installed on G430 v1, the on-board VOIP module is disabled.
G430 v2 has no on-board VOIP module.
Note:
The MP120 is capable of supporting new media services such as V.150.1. In the past, all DSP
cards were capable of supporting all codec types, albeit with various performance differences in
terms of point costs. However, the V.150.1 protocol is not supported on the older DAR cards.
G430 supports a maximum of 120 channels. If an MP120 is installed on a G430 v1, the on-
board VoIP module will be disabled.
The field replaceable VoIP module slot is located on the G430 main board. You must remove the
G430 cover to insert or remove a VoIP module.
