FW Version : 29.18.0
No Fault Messages : No Fault Messages
When a VoIP module is successfully installed in the optional VoIP module slot, output for the
slot includes:
MEDIA SOCKET #2
------------------
Type : MP80 VoIP DSP Module
Description : VoIP DSP resource with 80 channels
Serial Number : 07IS15812717
HW Vintage : 0
HW Suffix : B
Faults : No Fault Messages
When no VoIP module is installed in the optional VoIP module slot, the output for the slot
includes:
MEDIA SOCKET #2
------------------
Type : UNKNOWN
Description : UNKNOWN
Serial Number : UNKNOWN
HW Vintage : UNKNOWN
HW Suffix : UNKNOWN
Faults : NOT PRESENT
Related links
Inserting or removing an MP10, MP20, MP80, or MP120 VoIP module on page 74
Installing the upgrade memory kit
The upgrade memory kit enables increasing the number of announcement files on the G430 from
256 to 1024, by storing them on a removable compact flash. This also increases the total amount of
announcement time from 45 minutes to four hours. However, since the announcements are played
from RAM, you must also increase RAM to 512 MB.
The upgrade memory kit contains:
• 1 GB compact flash memory card
• Two RAM memory cards. For the G430, use the 512 MB RAM card.
Related links
Field Replaceable Unit upgrades and replacements on page 74
The upgrade memory kit on page 80
Compact flash memory cards on page 82
The upgrade memory kit
The G430 has a single RAM slot housing a 256 MB RAM card. If you wish to support an increased
number of announcement files, you must upgrade the G430 memory by replacing the 256 MB RAM
card with a 512 MB RAM card.
