If the switch is a PoE switch, you do not need to plug the IP telephone into a power supply.
2. Plug the telephone into the telephone port.
3. If the IP telephone is powered independently, plug the IP telephone into a power supply.
Check that the IP telephone is powered up.
Related links
IP telephone connections on page 44
ISDN BRI station connections
Each ISDN port on the MM720 or MM721 media module supports up to two ISDN BRI stations.
Note:
The MM720 and MM721 BRI media modules cannot be administered to support both BRI trunks
and BRI stations at the same time. However, the MM720 and MM721 BRI media modules
support combining both B-channels together to form a 128-kbps channel. Communication
Manager 3.1 enables combining B-channels, using BONDing, to form a higher bandwidth
connection. Finally, if the MM720 or MM721 BRI media module is administered to support BRI
stations, it cannot be used as a clock synchronization source.
Related links
Data and voice device connections on page 44
Connecting one ISDN BRI station to one ISDN port on page 45
Connecting two ISDN BRI stations to one ISDN port on page 45
Connecting one ISDN BRI station to one ISDN port
Procedure
Connect the station via a standard 8-pin BRI cable to one of the ISDN ports on an MM720 media
module.
Related links
ISDN BRI station connections on page 45
Connecting two ISDN BRI stations to one ISDN port
Procedure
1. Connect each station to an RJ-45 splitter that provides two RJ-45 4-pair jacks, and one
RJ-45 male connector.
See
the figure on page 46 for the correct wiring for the splitter.
2. Connect the male connector of the splitter to one of the ISDN ports on an MM720 or MM721
media module.
