equipment (on a rack) and then a single ground conductor can be routed from the same block to
an approved ground.
Danger:
Failure to install both grounds will void the Product Safety certifications (UL and the CE Mark)
on the product, as well as allow a hazard to be present that could result in death or severe
personal injury.
Related links
Ground conductor attachments on page 34
Approved grounds
There are two methods for equipment grounding.
The first is based on NFPA 70: National Electrical Code (NEC – a United States code).
Note:
Compliance with NFPA 70: NEC – or – with the equivalent local electrical code/grounding
requirements is mandatory.
The second is based on ANSI/EIA/TIA-607 (Commercial Building Grounding (Earthing) and
Bonding Requirements for Telecommunications).
Note:
ANSI/EIA/TIA-607 (TIA-607) defines an intra-building ground-wiring scheme for
communications equipment, and specifies equipment connection/grounding points according
to that scheme. TIA-607 assumes the underlying building grounding infrastructure is in
compliance with NFPA 70: NEC. Compliance with the NEC (or the equivalent local electrical
code/grounding requirements) is essential for the proper application of TIA-607.
Compliance with NFPA 70: NEC will provide suitable grounding for the Avaya equipment. TIA-607
provides an enhanced, communications-specific grounding scheme: where TIA-607 has been
implemented the Avaya equipment shall be grounded per this method.
Important:
• Ensure that the installation site has access to approved grounds and that either a trained
technician or a licensed electrician will be verifying all grounds and installing the
Supplementary Ground Conductor.
• If you have difficulty interpreting the grounding methods in this document, Avaya
recommends obtaining the services of a certified power contractor or auditor prior to
system installation or cutover.
Warning:
Failure to follow grounding recommendations can result is a system installation that is:
• Unsafe for personnel handling or using the equipment
• Not properly protected from lightning or power transients
Installing the Branch Gateway and EM200
