Type : MP80 VoIP DSP Module
Description : VoIP DSP resource with 80 channels
Serial Number : 07IS15812717
HW Vintage : 0
HW Suffix : B
Faults : No Fault Messages
When no VoIP module is installed in the optional VoIP module slot, the output for the slot
includes:
MEDIA SOCKET #2
------------------
Type : UNKNOWN
Description : UNKNOWN
Serial Number : UNKNOWN
HW Vintage : UNKNOWN
HW Suffix : UNKNOWN
Faults : NOT PRESENT
Installation of the upgrade memory kit
By using the upgrade memory kit, you can increase the number of announcement files on the
G430 from 256 to 1024 by storing the files on a removable compact flash. You can also increase
the total announcement time from 45 minutes to 4 hours. However, because the announcements
are played from RAM, you must also increase RAM to 512 MB.
Note:
The G430 hardware vintage 3 does not require a new memory card. For more information
about checking the hardware vintage, see
Checking the G430 hardware vintage on page 85.
The upgrade memory kit contains:
• One 1 GB compact flash memory card
• One memory card with 512 MB of RAM: Only for G430 v1 and G430 v2
The upgrade memory kit
The G430 has a single RAM slot housing a 256 MB RAM card. If you wish to support an increased
number of announcement files, you must upgrade the G430 memory by replacing the 256 MB
RAM card with a 512 MB RAM card.
The RAM slot is located on the G430 main board. You must remove the G430 cover to replace a
RAM card. This procedure includes the following steps:
1.
Removing The G430 cover on page 67.
2.
Replacing The RAM card on page 74.
3. Replacing The G430 cover on page 72.
Field Replaceable Unit upgrades and replacements
July 2018 Deploying and Upgrading Avaya G430 Branch Gateway 73
