Attaching ground wires for purchased ground blocks
Procedure
1. Cut the Supplementary Ground Conductor (which has one end attached to the grounding
screw on the chassis) to the length needed to terminate it into one of the terminals of the
ground block.
Do not coil the Supplementary Ground Conductor.
2. Attach one end of the remaining 10 AWG (4 mm
2
) ground wire to one of the terminals in
the ground block and the other end to an approved ground.
3. Cut this ground wire to the length needed to reach the approved ground.
Do not coil this wire.
Result
Note:
The ground block is for use with more than one Branch Gateway or EM200 in the rack. If the
ground block is to be used, you must supply it and have it installed by an electrician.
Related links
Ground conductor attachments on page 34
Attaching ground wires for unused ground blocks
Procedure
1. Attach the Supplementary Ground Conductor to an approved ground.
2. Connect the AC power cable to the inlet receptacle on the rear of the chassis.
Result
Note:
If two PSUs are installed in the Branch Gateway, the PWR LED blinks if only one PSU is
connected to power, and stays on if both PSUs are connected to power.
Related links
Ground conductor attachments on page 34
Ground conductor attachments
