2. Unscrew the locking screw attaching the VoIP module to the motherboard (see the
figure on page 69).
3. Open the latches on both sides of the module slot.
The module lifts up.
4. Pull out the module.
Hold the module only at the edges.
Replacing the G430 cover
About this task
Electrostatic alert:
Do not touch any components on the printed circuit board.
Procedure
1. Place the G430 cover back on the unit.
2. Screw in the 8 cover screws you previously removed.
Their locations are indicated by small arrows etched into the cover:
• One screw on the top (see the figure on page 67).
• Four screws on the right side (see
the figure on page 67).
• Three screws on the left side (see the figure on page 67).
3. Attach the mounting brackets to the G430, if applicable.
4. Replace the G430 in the rack or mount on the wall, if applicable.
5. Re-connect all cables (data and power) that you disconnected from the G430 and its
media modules, both front and rear.
6. Connect the G430 power cable into a mains socket.
7. Use the show platform mainboard CLI command to make sure the G430 is working
properly.
For example, when the G430 is working properly, output includes:
MAINBOARD BOARD
---------------
Type : G430
Description : Avaya Inc., G430 Media Gateway
Serial Number : 08IS26191007
HW Vintage : 4
HW Suffix : F
FW Version : 29.18.0
No Fault Messages : No Fault Messages
When a VoIP module is successfully installed in the optional VoIP module slot, output for
the slot includes:
MEDIA SOCKET #2
Upgrading and replacing Field Replaceable Units
July 2018 Deploying and Upgrading Avaya G430 Branch Gateway 72
