The field replaceable VoIP module slot is located on the G430 main board. You must remove the
G430 cover to insert or remove a VoIP module.
Procedure
1. Removing the G430 cover on page 67
2. Inserting a VoIP module on page 69
3.
Removing a VoIP module on page 71.
Skip this step if you are inserting a module into an empty slot.
4. Replacing the G430 cover on page 72
Removing the G430 cover
About this task
Voltage:
Disconnect the G430 from the external power source before proceeding.
Electrostatic alert:
Do not touch any components on the printed circuit board.
Procedure
1. Disconnect the G430 power cable from the mains power supply.
2. Note to which connector each cable is connected, so that you can reconnect them
correctly.
3. Disconnect all cables (data and power) connected to the G430 and the media modules,
both front and rear.
4. Remove the G430 from the rack or wall, if it is wall or rack mounted.
5. If mounting brackets are attached to the G430, remove them.
6. Unscrew the 8 cover screws, indicated by small arrows etched into the cover:
Remove one screw from the top (see
the figure on page 68).
Remove four screws from the right side (see the figure on page 68).
Remove three screws from the left side (see the figure on page 68).
7. Lift the cover off the G430.
Field Replaceable Unit upgrades and replacements
July 2018 Deploying and Upgrading Avaya G430 Branch Gateway 67
Comments on this document? infodev@avaya.com
