About installation and cabling
Issue 9.1 June 2006 115
Figure 16: Linking Units in Multiple Racks
Figure notes:
1. Short Octaplane cable (X330SC)
2. Redundancy cable (X330RC)
3. Long cable (X330LC)
You have now mounted the fully equipped Avaya G700 Media Gateway in the rack, and cabled
units together as described in the planning documents. When all the units are mounted, and
cabled, you are ready to connect to electrical ground conductors.
1
2 3
