Issue 9.1 June 2006 733
Appendix A: Technical information
This appendix collects some of the detailed technical information you will need to install the
Avaya G700 Media Gateway with an Avaya S8300 Media Serve. More complete information
can be found in Hardware Description and Reference for Avaya Communication Manager,
555-245-207.
Avaya G700 Media Gateway Technical Specifications
Table 44: Technical Specifications provides detailed information on the physical dimensions
and tolerances of the G700 Media Gateway.
Table 44: Technical Specifications
Chassis Dimensions
Height 2U (3.5
in)
88 mm Depth 17.7 in 450 mm
Width 19 in 482.6
mm
Weight
empty
22.25 lbs 10 kg
Weight 34-27 lbs 16-12 kg
Required Clearances
Front 12 in 30 cm consistent with EIA 464 data rack
standards
Rear 18 in 45 cm
Temperature Tolerances
Recommended 65 to 85 deg Farenheit 18 to 29 deg Celsius
Continuous operation +41 deg F to +104 deg
F
5 deg C to 40 deg C
BTU per Hr 1218
1 of 2
