DADman Software 18
Line Input Channel Strips
The Line input channel strips provide the following controls:
Phase Invert (Ph)
Click to enable (or disable) phase inversion.
Mute (M)
Click to mute (or unmute) the channel.
Max
Sets the unity gain value for the Level fader.
Level Meter
Displays the input signal level.
Fader
Move to adjust the input line signal level by +/–1.5 dB (0 = the selected Max dBu value).
dB Display
Displays the gain adjustment to the input signal in dB.
Label
Click to change the label (name) for the channel.
DA Section
The DA section controls all analog outputs in the MTRX Studio.
Line Input Channel Strip
DA section
Mute
Channel Label
Max dBu
Phase Invert
Level meter
Level fader
dB display
