Service Manual
6-1
6. DISASSEMBLY
Service Tools
Procedure for Disassembly and Reassembly
6.1 Service Tool
Table 6.1 describes the maintenance tools necessary for the maintenance of this equipment.
No
Name
Description
1
Minus screwdriver
Idler pulley module screw
2
Philips screwdriver
(magnetic)
Nominal No.2 M3, M4
3
Oil
Shell “Terrace Oil 46”
4
Grease
Shell “Alvania Grease
No.2”
5
Alcohol (Isopropyl 91% >)
Cleaning
6
Digital voltmeter
With 0.01 V range
7
Oscilloscope
100 MHz or more with
external sweep
8
Blower
Cleaning
Table 6.1 Maintenance tools
