Avision @V6600 - Removing ADF Chassis

Service Manual
6-17
6.2.9 Removing ADF Chassis
1. Remove the ADF Front Cover as described in the preceding section 6.2.5.
2. Remove the 2 Sensor Units on the front case as described in the preceding section
6.2.6.
3. Remove the Sensor Board as described in the preceding section 6.2.7.
4. Remove the ADF Board as described in the preceding section 6.2.8.
5. Remove the 3 fixing screws on the ADF chassis.
