Service Manual
1. INTRODUCTION
General Notes for Servicing
General Description
The manual describes areas to be maintained, the detailed installation, the disassembly,
and the component replacement procedures as well as the main trouble shooting guides.
Please take your time to read this manual thoroughly to obtain comprehensive knowledge
about the scanner before serving the unit.
1.1 General notes for servicing
(1) Before trying to disassemble the scanner, make sure the power supply cord of the
scanner is disconnected from the power outlet. Under any circumstance, do not
remove or install the connectors on the scanner with the power supply turned ON.
(2) Use caution not to drop small parts or screws inside the unit when disassembling and
reassembling. If left inside, they might cause the malfunction of the unit.
(3) Do not pull the connector cable when disconnecting it. Hold the connector.
(4) When carrying the scanning head unit, put it in an anti-static bag.
(5) Keep the document table glass surface always clean. If contaminated, use a dry
clean cloth for cleaning.
(6) Use caution not to injure your fingers or hands when disassembling or reassembling
the unit.
