Instructions: FRITZ!Box Placement
1. In compliance with the rules mentioned above, select a suitable
location for the FRITZ!Box.
2. Place the FRITZ!Box in this location.
Instructions: Mounting FRITZ!Box on the Wall
Damage to electric wiring or gas or water pipes during drilling can
present a significant danger. Before mounting the FRITZ!Box on the
wall, make sure that there are no electricity lines, gas or water pipes
located where you need to drill the holes. If necessary, check the site
with a pipe detector or consult with qualified experts.
1. In compliance with the rules mentioned above, select a suitable
location for mounting the FRITZ!Box on the wall.
2. Pick up the FRITZ!Box and measure the distance between the
centers of the hanging holes.
The hanging holes are located on the back of your FRITZ!Box.
3. Mark two spots for drilling at the distance you measured at the
desired location on the wall.
4. Drill two holes and insert screws.
5. Hang the FRITZ!Box on the wall with the socket strip down.
FRITZ!Box 7590 AX 33
