Connecting to Electric Power

Overview

Connect the FRITZ!Box to the power supply.

Please Note

• If at all possible, do not use any power strips or extension cords.

• If it is not possible to avoid using a socket strip or an extension

cord, then do not connect multiple extension cords or socket strips

to each other.

• Use only the power adapter included with delivery.

Instructions: Plugging In to Electrical Power

1. Connect the power adapter to the socket on the FRITZ!Box la-

beled Power.

USBPowerLAN 4LAN 3LAN 2LAN 1WANFON 2FON 1DSL

2. Plug the other end into an electrical outlet.

FRITZ!Box 7590 AX 34

Connecting

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

Questions and Answers:

Need help?

Do you have a question about the AVM FRITZ!Box 7590 AX and is the answer not in the manual?

AVM FRITZ!Box 7590 AX Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2400 Mbit/s
WLAN data transfer rate (first band)	1200 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN interface type	Gigabit Ethernet
Mobile network generation	-
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Product type	Tabletop router
Product color	White
LED indicators	DSL, WLAN, WPS
Power source type	AC
Power consumption (typical)	16 W
Cables included	DSL, LAN (RJ-45)
Package type	Box
Package depth	68 mm
Package width	305 mm
Package height	240 mm
Package weight	1125 g
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990
