Enabling Mesh for FRITZ!Repeaters and FRITZ!Powerline
Overview
In order to benefit from the advantages of Mesh, enable Mesh for all
FRITZ!Repeater and FRITZ!Powerline devices located in the home net-
work of your FRITZ!Box.
Requirements
• FRITZ!Repeater / FRITZ!Powerline with FRITZ!OS 7 or later
Instructions: Enabling Mesh for a FRITZ!Repeater
1. Open the FRITZ!Box user interface; see page56.
2. Click on Home Network > Mesh in the menu.
3. The FRITZ!Box is displayed in the overview with the Mesh
enabled symbol. If the symbol is also displayed for
the FRITZ!Repeater, then Mesh is already enabled for
the FRITZ!Repeater. If the symbol is missing next to the
FRITZ!Repeater, continue with the next step.
4. Press the button on the FRITZ!Repeater.
After the button is released, the WLAN or Connect LED on the
FRITZ!Repeater flashes rapidly.
5. Within 2minutes, start WPS on the FRITZ!Box. Do this by
pressing the Connect/WPS button until the Info LED starts flash-
ing.
Mesh is enabled and the FRITZ!Repeater is displayed in the overview
marked with the Mesh enabled symbol.
Instructions: Enabling Mesh for FRITZ!Powerline
1. Open the FRITZ!Box user interface; see page56.
2. Click on Home Network > Mesh in the menu.
FRITZ!Box 7590 AX 91
Mesh with FRITZ!
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
