Instructions: Connecting to a Cable Modem

1. Insert one end of the LAN cable into the LAN (Ethernet) port on

the cable modem.

2. Insert the other end of the LAN cable into the WAN socket on the

FRITZ!Box.

3. Connect a computer with the FRITZ!Box, see page36 or see

page38.

4. Set up the internet connection for connections via cable in the

FRITZ!Box; see page70.

FRITZ!Box 7590 AX 48

Option: Connecting to a Modem or Router

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

Questions and Answers:

Need help?

Do you have a question about the AVM FRITZ!Box 7590 AX and is the answer not in the manual?

AVM FRITZ!Box 7590 AX Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2400 Mbit/s
WLAN data transfer rate (first band)	1200 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN interface type	Gigabit Ethernet
Mobile network generation	-
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Product type	Tabletop router
Product color	White
LED indicators	DSL, WLAN, WPS
Power source type	AC
Power consumption (typical)	16 W
Cables included	DSL, LAN (RJ-45)
Package type	Box
Package depth	68 mm
Package width	305 mm
Package height	240 mm
Package weight	1125 g
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990
