APPENDIX 1 SPECIFICATIONS
59
APPENDIX 1 SPECIFICATIONS
 4CH Models
Model 1 Model 2 Model 3 Model 4 Model 5
 Video
Video System
NTSC / PAL
(auto detection)
Video Compression Format H.264
Video Signal
AHD / TVI / 960H TVI / 960H AHD / TVI / 960H
AHD (Optional) /
TVI / 960H
Video Input
(
Composite video signal 1 Vp-p 75Ω BNC)
4 channels
Video Output BNC YES
VGA YES
HDMI YES
 Record & Backup
Maximum Recording Rate 1080P 1920 x 1080 pixels with 60 IPS
720P 1280 x 720 pixels with 120 IPS
QHD 960 x 540 pixels with 120 IPS
Frame 704×480 pixels with 120 IPS <NTSC> / 704×576 pixels with 100 IPS <PAL>
Field 704x240 pixels with 120 IPS <NTSC> / 704×288 pixels with 100 IPS <PAL>
CIF 352×240 pixels with 120 IPS <NTSC> / 352×288 pixels with 100 IPS <PAL>
Recording Mode Manual / Timer / Motion / Alarm / Remote
Pre-alarm Recording YES
Playback Channel 4CH
Quick Search Time / Motion / Alarm search mode
Backup Device USB 2.0 flash drive / Network
Regular Backup YES
 Audio
Audio Input 1 audio input
Audio Output 1 audio output (Mono)
 General
Hard Disk Storage Up to 2 SATA HDDs
SATA Interface YES
eSATA Interface
(For external disk array connection)
YES NO YES NO
Image Quality Setting SUPER BEST / BEST / HIGH / NORMAL
USB Mouse Control YES
Motion Detection Area 16 × 12 grids per channel
Motion Detection Sensitivity 3 adjustable parameters for accurate detection
Event Notification Push Video / Push Status / FTP / E-Mail
Push Status /
FTP / E-Mail
Picture Zoom 2X digital zoom
PTZ Control YES
Alarm I/O 4 inputs, 1 output NO 4 inputs, 1 output NO
RS485 YES NO YES NO
IR Remote Control YES (IR receiver built-in)
Key Lock (Password Protection) YES
User Level 4 user levels for different access privilege
Video Loss Detection YES
Camera Title Supports up to 12 letters
Video Adjustable Hue / Saturation / Contrast / Brightness
Date Display Format YY/MM/DD, DD/MM/YY & MM/DD/YY
