HARDWARE OVERVIEW
1
1. HARDWARE OVERVIEW
Note: The functions on the front panel and rear panel may vary, depending on the model you have.
1.1 Package Content
 Standard Package
 DVR  HDD screws
 Adapter & power cord  Quick Start
 Optional Accessories
 I/O terminal block  IR Remote Controller
 USB Mouse
1.2 Front Panel
1) LED Indicators
DVR is powered on.
The hard disk is reading or recording.
An alarm is triggered. (For selected models only)
Timer recording is on. (For selected models only)
Under playback status. (For selected models only)
2) CH1 ~ 16 / 1 ~ 8 / 1 ~ 4
Press the channel number buttons to select the channel to display.
3)
Press to show the 4 channel display mode.
4) SEQ
Press to display each channel in full screen one by one starting from CH1. When the last channel is displayed, it
will repeat from CH1 again. To exit this mode, press “SEQ” again.
5) SLOW
In the playback mode, press to show slow playback.
6) ZOOM
Press to enlarge the picture of selected channel in the FRAME or FIELD recording mode.
7) PLAY
Press to playback the latest recorded data.
8) LIST (Event List Search)
Press to quickly search the recorded files by event types, or select FULL to show all the event logs.
To quickly search the time you want, select “QUICK SEARCH”. For details, please refer to “5.4.2 Event Search” at
page 18.
9) ENTER
Press “ENTER” to confirm the setting.
10) MENU
Press “MENU” to enter the main menu.
