F. PGM/SUB/AUX-1/AUX-2 BUTTONS
The PGM, SUB, AUX-1, AUX-2 buttons enable or disable the output signal routing on the related BUS, the RGB LEDs
under the related button has three different states:
1) LED OFF = BUS disabled.
2) LED ON in full light = BUS enabled + Channel ON.
3) LED ON in half-light = BUS ON + Channel OFF.
The Different in BUS’s status, it's not associated with the source, like EQ and GAIN but with the physical channel.
when you changing the source, the BUS’s status will not change.
It’s possible to set AUX-1 and AUX-2 to be POST-Fader or PRE-Fader, this choice is settable in the settings menu of
every channel’s input source.
When a channel switch from ON to OFF or standby status, the related LEDs switches from ON Colour to standby
colour. this function allows us to understand the channel and BUS's status.
ON/OFF channel status could depend on:
- ON/OFF of ON/START button.
- Fader position.
