D. ENCODER FOR THE MENU NAVIGATION
- The 4 knobs (1) (2) (3) (4) allow you to adjust and confirm the menu parameters.
- It is also possible to PUSH the knob to confirm the parameter setting.
- Menus are designed to have a perfect matching between graphics and knobs.
- Parameter changes will be directly applied to the audio of the aired channel.
- The yellow value represents the stored value.
- While a knob is being moved the circle becomes white. A white value appears in the
middle of the circle. The new value represents an instantaneous value that is different
from the stored one.
- Push the related knob to confirm the parameter changes. Once you have confirmed the
new value, the graphic will become yellow again.
- At the ESC pressing or at the next screen change if the changes will not be confirmed,
the value will be restored to the one previously saved.
