ENGINEERING DOCUMENTATION 7
_____________________________________________________________________________________________
The metrological parameters of the balance are indicated on the rating plate.
Installation
SE-01/A
SE-01/N/18 SE-01/N/25
Installation system
Fixing
2 holes Ф5,
spacing 59mm
2 holes Ф5,
spacing 6.30in
2 holes Ф5,
spacing 7.99in
