6 Technical data
Parameter SE-01/A SE-01/N/18 SE-01/N/25
Max verification units number
6000e
(3000e/range - in multi range scale)
Part of error(pi)
0,5
Accuracy class
III
Readability (d)
1, 2, 5, 10, 20 (g. dkg, kg)
Verification unit (e)
free
Tare range
full
Input signal range
2,4
÷
9,5mV (option 10mV)
4,8÷19mV (option 20mV)
9,6÷38mV (option 40mV)
19,2÷72mV (option 80mV)
Minimal input signal (
∆
Umin/e) 0,4
µ
V/e
Working tem
perature
-10
÷
40
o
C
Max sensor number
6szt.
Sensor excitation
5V AC 25Hz
Sensor impedance range(RL)
40
÷
4000
Ω
Sensor connecting
system 4 or 6
-
line for sensor
system 6- line for sensor
Maximal cable length (l/S)
75m/mm
2
Opto
-
isolator output load capacity
(option)
100mA, 24V
Casing option
OSA
OSN
ODN
Dimensions
190x140x70mm
200x146x77mm
238x182x77mm
Casing security level (IP)
-
IP65
IP65
Power supply
230V, 50Hz, 6VA
Weight
1,8kg
2,3kg
2,3kg
The available ranges of double-range balances:
Maximum
load (Max2/Max1)
15/6kg
30/15kg
60/30kg
120/60kg
150/60kg
200/60kg
300/150kg
Minimum load
40g
100g
200g
400kg
400g
400g
1kg
Readability (d2/d1))
5/2g
10/5g
20/10g
50/20g
50/20g
100/50g
100/50g
Verification units
(e2/e1)
5/2g
10/5g
20/10g
50/20g
50/20g
50/20g
100/50g
