4. Terminate all cables at the termination block according to
the system designer's specifications and the diagram on the
Remote Unit rear panel. It is important that each conductor
is correctly identified before being terminated.
3.2.5.2 Set Option Jumpers & Switches
The BVFREPEM is a Repeater and a Power Monitor as well as an
interface for the BVOCDTA.
Table 3.8 shows the Repeater /
Power monitor options and Table 3.9 the BVOCDTA options.
Table 3.8 — BVFREPEM Repeater / Power Monitor Settings
Table 3.9 — BVFREPEM BVOCDTA Options
NOTE: As an aid, the Blue Block is also labelled with the connection
details to indicate where each conductor should be terminated.
CA U T I O N
The OmniCare EVC System Remote Units can be damaged if
either of the following situations occur:
• If Power is connected across the Data pair,
• If Power is reversed i.e. 0V and +V swapped.
NOTE: It is important to ensure each connection to the termination block
is made correctly, the screw terminals are tightened sufficiently, and the
blue connector block is pushed fully into the housing.
The majority of problems encountered during commissioning are due to
loose, poor, or incorrect terminations on Remote Units that impair the
integrity of the ring.
Status Option
LK1&2 Fitted Reduces CANbus termination resistors to 75Ω
LK3 Fitted Increases the output level of the CANbus drivers
SW1 "ON" Enables power monitoring
SW2 "ON" Modifies voltage threshold for power monitoring
(only if SW1 set to "ON")
SW3 SW4 Option
"OFF" "OFF" Toilet Alarm interface is Disabled
"ON" "OFF" Toilet Alarm interface for FireCare
"OFF" "ON" Toilet Alarm interface for AssureCare
"ON" "ON" Toilet Alarm interface for OmniCare
