Type code
BTL PF1400-0500-C12NL3A0-000S04
Construction:
P = Profile
Housing geometry:
F = Profile housing, flat 35×20.8mm
Installation:
0 = without mounting clamps
1 = with mounting clamps (BTL6-A-MF07-A-PF/M5)
Mechanical zero point:
4 = Zero point at 67mm
Measuring length (4 digits):
0500 = metric specification in mm; measuring length 500 mm (0025...4000)
Interface:
NL = IO-Link
IO-Link version:
2 = V1.1, COM2
3 = V1.1, COM3
IO-Link version:
A = Position; 1magnet
B = Position and speed; 1magnet
C = 2positions; Flexible Magnet Mode
D = 2positions and 2speeds; Flexible Magnet Mode
G = Smart Transducer Protocol
Electrical connection:
S04 = 4-pin, M12 plug
954881_AA ∙ EN ∙ E22 ; Subject to modification.
BTL PF _ 400- _ _ _ _ -C12NL _ _ -0-000S04
Magnetostrictive Linear Position Sensor – Profile Style
