Banner LTF Series User Manual

© Banner Engineering Corp. www.bannerengineering.com 12
SENSOR PROGRAMMING
3.5.2.1. Window Size
The A_OUT > TchMid > WndSize option sets the window size that the Midpoint TEACH uses to set the 4 mA (0 V) and 20 mA (10 V) setpoints.
The taught surface must be inside the defined sensing range, and at least one setpoint (with offset applied, if any) must be located within the
sensing range.
The Analog Output window size is a different setting than the Discrete Output window size when defined using the push buttons.
Navigate: MENU > A_OUT > TchMid > WndSize
Remote Input: Available
1) Access the Window Size mode.
2) Set the window size.
3.5.2.2. TEACH 12 mA (5 V)
The Tch12mA (Tch5V) option sets the midpoint that determines the actual measurement window.
Navigate: MENU > A_OUT > TchMid > Tch12mA (Tch5V)
Remote Input: Available
Button Instructions
1) Present the target.
2) Access the TEACH 12 mA (5 V) mode and TEACH the sensor.
Parameters LTF12 LTF24
Window Size Minimum 10 mm 10 mm
Window Size Maximum 11950 mm 23950 mm
Range 50 mm to 12000 mm 50 mm to 24000 mm
Default Window Size 2000 mm 2000 mm
Method Action Result
Push Button Navigate: MENU > A_OUT > TchMid > WndSize
"WndSize" and the current window size value
display.
Remote Input
a. Double-pulse the remote input to enter setup mode.
b. Three-pulse the remote input to enter window size
mode.
a. "REMOTE SETUP" displays.
b. "WndSize" and the current window size
value display.
Method Action Result
Push Button
a. Use the Up and Down buttons to set the desired window size—the value changes in
increments of 2.
b. Press Enter to save the new value.
a. "WndSize" and the new value
display.
b. The new value flashes and the sensor
returns to "TchMid WndSize".
Remote Input
(Sets A_OUT and
D_OUT window
Size)
Pulse the remote input 1 to 6 times to select the desired window size.
1 pulse: 10 mm
2 pulses: 20 mm
3 pulses: 100 mm
4 pulses: 500 mm
5 pulses: 2000 mm
6 pulses: 11950 mm for the LTF12; 23950 mm for the LTF24
The new value flashes and the sensor
returns to Run mode.
Action Result
Present the target.
The target's analog output measurement and distance
measurement values display.
TT
T
TT
T
T
T
