Banner LTF Series User Manual

19 © Banner Engineering Corp. www.bannerengineering.com
SENSOR PROGRAMMING
Navigate: MENU > D_OUT > TchMid > TchMdPt
Remote Input: Available
Button Instructions
1) Present the target.
2) Access the TEACH midpoint mode and TEACH the sensor.
Remote Input Instructions
1) Access the TEACH mode.
2) Present the target.
3) TEACH the sensor.
3.6.2.3. Window TEACH Offset
Use the D_OUT > TchMid > Offset menu to set an offset from the taught distance used during a Midpoint TEACH. By default, the value is 0 mm
because the window is centered around the taught distance. A positive offset value always shifts the window towards the sensor.
3.6.3. Adjust Switch Point One
The AdjSPt1 option manually adjusts the value of the switch point one threshold for the Discrete Output when the sensor is in Window mode.
The value is adjustable within the sensor's range. It is required to be maintain the minimum window size between switch points. This menu is not
available when the sensor is in Switch, Alarm, or Health mode.
Navigate: MENU > D_OUT > AdjSPt1
Remote Input: Not available
Action Result
Present the target.
The target's analog output measurement and distance
measurement value display.
Action Result
Navigate: MENU > D_OUT > TchMid > TchMdPt
"TchMdPt Teaching" displays while the sensor is
being taught.
TEACH Accepted
The new value is shown on the second line of the
display and flashes before it is saved and the sensor
returns to "TchMid TchMdPt".
TEACH Not Accepted
"FAIL" and a warning message display, and the
sensor returns to "TchMid TchMdPt".
Action Result
Single-pulse the remote input.
"RMT TCH" and the current measurement value
display.
Action Result
Present the target.
"RMT TCH" and the target's measurement value
display.
Action Result
Five-pulse the remote input.
"TchMdpt Teaching" displays while the sensor is
being taught.
TEACH Accepted
The new value displays on the second line of the
display, flashes, and the sensor returns to Run mode.
TEACH Not Accepted
"FAIL" and a warning message display, the sensor
returns to step 2, and "RMT TCH" displays.
T
TT
T
T
T
T
T
T
T
