Banner LTF Series User Manual

© Banner Engineering Corp. www.bannerengineering.com 20
SENSOR PROGRAMMING
Default: 50 mm
3.6.4. Adjust Switch Point Two
The AdjSPt2 option manually adjusts the value of the switch point two threshold for the Discrete Output when the sensor is in Window mode.
The value is adjustable with the sensor's range. It is required to be maintain the minimum window size between switch points. This menu is not
available when the sensor is in Switch, Alarm, or Health mode.
Navigate: MENU > D_OUT > AdjSPt2
Remote Input: Not available
Default: 12000 mm for LTF12; 24000 mm for LTF24
3.6.5. TEACH Switch Point
The TchSPt option teaches the distance at which the switch point threshold is placed when the Discrete Output is in Switch mode. This menu is
not available when the sensor is in Window, Alarm, or Health mode.
Navigate: MENU > D_OUT > TchSPt
Remote Input: Available
Button Instructions
1) Present the target.
2) Access the switch point TEACH mode and TEACH the sensor.
Remote Input Instructions
1) Verify the sensor is in Switch mode.
2) Access the TEACH mode.
3) Present the target.
4) TEACH the sensor.
Action Result
Present the target. The target must be within the sensor's range.
The target's analog output measurement and distance
measurement value display.
Action Result
Navigate: MENU > D_OUT > TchSPt
"TchSPt Teaching" displays while the sensor is being
taught.
TEACH Accepted
The new value is shown on the second line of the
display and flashes before it is saved and the sensor
returns to "D_OUT TchSPt".
TEACH Not Accepted
"FAIL" and a warning message display, and the
sensor returns to "D_OUT TchSPt".
Action Result
Single-pulse the remote input.
"RMT TCH" and the current measurement value
display.
Action Result
Present the target.
"RMT TCH" and the target's measurement value
display.
T
