Banner LTF Series User Manual

31 © Banner Engineering Corp. www.bannerengineering.com
SENSOR PROGRAMMING
Remote Input: Not available
Default: Normal
3.9.4. Sleep
The Sleep option sets when the display is put to sleep. Four timing options are available: 1, 5, 15, or 60 minutes. Sleep mode is disabled by
default. Sleep occurs in Run mode and any menu. To wake the sensor and return to the last viewed mode or menu, press any button.
Navigate: MENU > DISPLAY > Sleep
Remote Input: Not available
Default: Disabled
3.10. Information Menu (INFO)
Use this menu to view model, part number (P/N), serial number (S/N), and firmware version (Version) information. Select one of these options
to view specific information for your sensor. This information is read-only.
Navigate: MENU > INFO
Remote Input: Not available
Figure 27: Information Menu Map
3.11. Reset Menu (RESET)
Use this menu to restore the sensor to the factory default settings.
Navigate: MENU > RESET. Select Yes to apply the factory defaults; select No to return to the Reset option without changing any sensor settings.
Remote Input: Eight-pulse the remote input
Figure 25: Normal Display Orientation Figure 26: Inverted Display Orientation
MENU INFO
or
or
Go Back to Parent Menu
Select Menu Item
Press to Save Setting
Press and Hold to Go Back
to Run Mode
INFO Version
INFO Model
Version 1.0.0
Model LTF12I
INFO P/N
P/N 94849
INFO S/N
S/N F..S..P..D..
