The Range advanced measurement behavior is affected by the Loss of Signal option. For additional information on advanced measurements,
see Trigger on page 26. The Range advanced measurement tracks a maximum and a minimum during the measurement period, and calculates
the range as follows:
Range = maximum distance – minimum distance
If the maximum and/or minimum measurements are outside of the taught setpoints, the Loss of Signal option determines how the range is calcu-
lated.
3.6. Discrete Output Menu (D_OUT)
Use this menu to view or change
• Setpoints
• Midpoint
• Mode
• Timers
• Polarity
Option Description
3.5 mA (0 V)
The Analog Output switches to this value 2 seconds after a loss of signal. When advanced measurements are enabled, the
Analog Output is updated to this value immediately upon the release of the trigger input. For Voltage models, this is 0 V.
(Default)
20.5 mA (10.5 V)
The Analog Output switches to this value 2 seconds after a loss of signal. When advanced measurements are enabled, the
Analog Output is updated to this value immediately upon the release of the trigger input. For Voltage models, this is 10.5 V.
Hold
The Analog Output holds the last value indefinitely during a loss of signal. When advanced measurements are enabled, the
last value is held across the triggered measurement periods.
Option Sensor Behavior in Range Mode
3.5 mA (0 V)
If the maximum or minimum measurement is outside of the taught setpoints, the sensor outputs 3.5 mA (0 V) to indicate an
out of range measurement.
20.5 mA (10.5 V)
If the maximum or minimum measurement is outside of the taught setpoints, the sensor outputs 20.5 mA (10.5 V) to indicate
an out of range measurement.
Hold The sensor limits the maximum and minimum measurements so that they cannot exceed the taught setpoints.
