Banner LTF Series User Manual

17 © Banner Engineering Corp. www.bannerengineering.com
SENSOR PROGRAMMING
3) Repeat steps 1 to 2 for the other switch point, if desired.
Remote Input Instructions
1) Access the TEACH mode.
2) Present the target.
3) TEACH the sensor.
4) Present the target.
5) TEACH the sensor.
Action Result
Navigate: MENU > D_OUT > Tch2Pt > TchSPt1
OR
Navigate: MENU > D_OUT > Tch2Pt > TchSPt2
The selected TEACH mode and "Teaching" display
while the sensor is being taught.
TEACH Accepted
The new value is shown on the second line of the
display and flashes before it is saved and the sensor
returns to the parent menu.
TEACH Not Accepted
"FAIL" and a warning message display, and the
sensor returns to the parent menu.
Action Result
Single-pulse the remote input.
"RMT TCH" and the current switch point value
displays.
Action Result
Present the switch point one target.
"RMT TCH" and the target's measurement value
display.
Action Result
Double-pulse the remote input.
"TchSPt1 Teaching" displays while the sensor is
being taught.
TEACH Accepted
The new value displays on the second line of the
display, flashes, and the sensor goes to "TchSPt2"
and the current measurement value.
TEACH Not Accepted
"FAIL" flashes, the sensor returns to step 2, and
"RMT TCH" displays.
Action Result
Present the switch point two target.
"TchSPt2" and the target's measurement value
display.
Action Result
Single-pulse the remote input.
"TchSPt2 Teaching" displays while the sensor is
being taught.
TEACH Accepted
The new value displays on the second line of the
display, flashes, and the sensor returns to Run mode.
TEACH Not Accepted
"FAIL" flashes, the sensor returns to step 2, and
"RMT TCH" displays.
T
TT
T
T
