P/N 133487 57
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Product Name
Instruction Manual
Operating Instructions
Input Status: If a safety output is OFF or turning OFF, line 5 of the
display indicates information about the input that is keeping the output
OFF.
Line 5 also indicates when a manual reset operation needs to be
performed.
NOTES:
• Line 5 changes to indicate each input when the status of more than
one input must be displayed.
• Press the Up arrow button to pause the screen on the current input.
• Press the Down arrow button to change the last line to the next
input. (Press the Down arrow button repeatedly to quickly cycle
through the inputs.)
• If more than one output is OFF, a small arrowhead indicates the
safety output to which the input messages correspond (see
Figure 6-3).
Input Device
Status Message
Cause and/or Required Action
Stop The safety input is in a state that causes the safety output to turn OFF.
Test
A start-up test needs to be completed on the safety input. To perform the test, cycle the input (Run-Stop-Run) to turn
the safety output ON.
Deactivate
A two-hand control input or an enabling device needs to be cycled (Run-Stop-Run) before the safety output will
turn ON.
Fault A problem has been detected with an input that controls the output.
Timed Out
The safety output is in enable mode and the enabling device active time limit has expired. Cycle the enabling device to
turn the output back ON, or turn the enabling device OFF and perform a system reset to exit Enable mode.
To Next Page
