2. CS-100 Specifications
2.2 CS-100 specifications
Base Unit
Weight
600g / 1.32lbs
Dimensions (HxWxD) 205mm x 115mm x 45mm (Min.) / 8.1” x 4.5” x 1.8” (Min.)
Po we r con s umption
Operation: 6W (typical) / 18W (max)
Standby: 2.6W (ECO standby) / 0.4W (Deep standby)
Warranty 3 years standard
Certifications FCC/CE
Anti-theft system
Kensington lock
Humidity
Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-conden sing
Temperature range
Operating: 0°C to +40°C (+32°F to +104°F)
Max: 3 5°C (95°F) at 3000m
Storage: -20°C to +60°C ( -4°F to +140°F )
Connections
1x Ethernet LAN
1x (back) + 1x (front) USB
Audio analog line out on mini jack socket (3.5mm )
Frequency band
2.4 GHZ and 5 G Hz
Reach
Adjustable with signal strength modulation; m ax. 30m (100 ft) between ClickShare
Button and ClickShare Base Unit
Wireless transmission protocol IEEE 802.11 a/g/n
Authentication protoco l WPA2-PSK in stand alone mode
iPad, iPhone and Android
compatibility
Sharing of documents, br owser, camera for both Andr oid and iO S dev ices ClickShare app
Audio Via HDMI, analog via Audio J ack 3.5mm
Number of simultaneous
connections
8
Number of sources simultaneous
on screen
1
Noise Level Fan less
Input resolutions
3840 x 2160 (max)
Output resolution
1920x1200
Frame rate
Up to 30 fps
Video outputs 1x HD MI
Extended d esktop
Available (depending on the driver of your graphics card)
Operating system Windows 7/8/8.1/10
Mac O S X 10.10/10.11
Android 4.1 and later (ClickShare app)
iOS 7.0 and later (ClickShare app)
Button
Weight 75 g/0.165 lb
Dimensions (HxWxD) 16.3 m m x 59.3 m m x 16 2.52 m m / 0.64” x 2.335” x 6.398”
Po we r con s umption Powered over USB
5V DC
350mA Typical
500mA Maximum
Frequency band 2.4 GHZ and 5 G Hz
6 R5900022 CS-100 16/02/2016
