13. Specifications
MAC13
640 x 480 35.00 66.67 1066 x 800 640 x 480
x
MAC16
832 x 624 49.72 74.55 4 1066 x 800 832 x 62
x
MAC19
1024 x 768 60.24 75.02 1066 x 800 1024 x 768
HP75 1024 x 768 62.94 74.92 1066 x 800 1024 x 768
HP72 1280 x 1024 78.13 72.00 1000 x 800 1280 x 1024
SUN66a
1152 x 90 0 61.85 66.00 1024 x 800 1152 x 800
SUN76a
1152 x 90 0 71.81 76.64 1024 x 800 1152 x 800
SUN66
1280 x 1024 71.68 66.68 1000 x 800 1280 x 800
SUN76
1280 x 1024 81.13 76.11 1000 x 800 1280 x 800
SGI72
1280 x 1024 76.92 72.30 1000 x 800 1280 x 800
SGI76
1280 x 1024 82.01 76.00 1000 x 800 1280 x 800
UXGA60
1600 x 1200 75.00 60.00 1066 x 800 1280 x 800
xxx
WUXGA60
1920 x 1200 74.04 59.95 1280 x 800 1280 x 800
Signals described in the Signal mode column can be input re gardless of the x m ark in t he Plug and Play column. For signals not
marked with x in the P lug and P lay column, the resolution may not be su pported ev en w
hen it is supported on the c omputer.
13.6 Specification of RGB signals in each computer mode of the projector, For
PHXG-91B
Overview
Plug and Play
8
Signal mode
Resolution
(H x V)
Horizontal
frequency
(kHz)
Verti-
cal fre-
quency
(Hz)
Normal mode
(H x V)
COM-
PUTER /
COMPO-
NENT
VIDEO IN-1
terminal
COM-
PUTER
/COM-
PONENT
DVI-D IN
(HDCP) ter-
minal
HDMI IN
terminal
TV60, 480i
(525i)
56
720 x 480 15.73 59.94 1024 x 768
TV50, 576i
(625i)
56
720 x 576 15.63 50.00 1024 x 768
1080i60
(1125i60)
5
1920 x 1080 33.75 60.00 1024 x 576
xx
1080i50
(1125i50)
5
1920 x 1080 28.13 50.00 1024 x 576
xx
480p (525p)
5
720 x 480 31.47 59.94 1024 x 768
xx
576p (625p)
5
720 x 576 31.25 50.00 1024 x 768
xx
720p60
(750p60)
5
1280 x 720 45.00 60.00 1024 x 576
xx
720p60
(750p50)
5
1280 x 720 37.50 50.00 1024 x 576
xx
1080p60
(1125p60)
5
1920 x 1080 67.50 60.00 1024 x 576
xx
1080p50
(1125p50)
5
1920 x 1080 56.25 50.00 0 1024 x 576
xx
CGA70
640 x 400 31.47 70.09 1024 x 640
CGA84
640 x 400 37.86 84.13 1024 x 640
CGA85
640 x 400 37.86 85.08 1024 x 640
VGA60
640 x 480 31.47 59.94 1024 x 768
xxx
VGA72
640 x 480 37.86 72.81 1024 x 768
x
8. Signals marked with x in the Plug and Play column are described in EDID (extended display identification data) of the projector.a
R5905597 PHXX SERIES 20/05/2014 113

Barco PHWU-81B Specifications

General

Matrix size	0.67 \
Matrix type	DMD
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Projector brightness (economic mode)	5450 ANSI lumens
Focal length range	- mm
Lamp power	350 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	SDI
Noise level	44 dB
Noise level (economic mode)	39 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	910 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	690 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	660 mm
Width	510 mm
Height	263 mm
Weight	21000 g
Package depth	840 mm
Package width	650 mm
Package height	415 mm
Package weight	26500 g
