Barco PHWU-81B User Manual

A. Option lens H LENS 0.8-1.0, 2.8-4.5 or 4.5-8.7
250 635 212 538 132 33 7 1 65 4.2 206 5.2 65 164 24 62 20 52
300 762 254 646 159 40 4 1 98 5.0 248 6.3
77
197 29
75
25 62
A.6 Specifications H LENS 2.8-4.5
General
F No. : F2.2-2.7
Focal distance : f=40.7-65.1 mm
Zoom/focus : electrical drive
H0
H0
W1
H1
H2
H
L
W1
W
L
W1
H1 H2
H
L
W1
W
L
C
C
A
A
III
Image A-6
I Fornt projection
II Front projection, ceiling mounted
A Maximum projection area
C Center of the lens
XGA mode l with H LENS 2.8-4.5
The numbers are approximate and may be slightly different from the actual meas ureme nts.
Screen size (4:3) Projector distance (L) Lens shift height
9
Lens shift
width
Diagonal
size
Width (W) Height (H) Shortest
(Wide)
Longest
(Tele)
Movement
distance (H1)
Movement
distance (H2)
Movement
distance
(W1)
inch
cm
inc
cm
inch
cm
inch
m
inch
m
inch
cm
inch
cm
inch
cm
40 102 32 81 24 61
--
1483.812302638
60 152 48 122 36 91 136 3.5 224
5.7
18 46 3 9
5
12
80 203 64 163 48 12 2 1 83 4.7 301 7.6 24 61 4 11 6 16
100 254 80 203 60 15 2 2 30 5.8 377 9.630 9.6 76 6 14 8 20
150 381 120 305 90 22 9 3 48 8.8 568 14.4 45 114 8 21 12 30
200 508 160 406 120 30 5 4 65 11.8 759 19.3 60 152 11 28 16 41
250 635 200 508 150 38 1 5 83 14.8 951 24.1
75
191 14 36 20 51
300 762 240 610 180 45 7 7 01 17.8 1142 29.0 90 229 17 43 24 61
WXGA model with H LENS 2.8-4.5
The numbers are approximate and may be slightly different from the actual meas ureme nts.
Screen size (16:10) Projector distance (L) Lens sh ift height
9
Lens shift
width
Diagonal
size
Width (W) Height (H) Shortest
(Wide)
Longest
(Tele)
Movement
distance (H1)
Movement
distance (H2)
Movement
distance
(W1)
inch
cm
inc
cm
inch
cm
inch
m
inch
m
inch
cm
inch
cm
inch
cm
R5905597 PHXX SERIES 20/05/2014 123

Barco PHWU-81B Specifications

General

Matrix size	0.67 \
Matrix type	DMD
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Projector brightness (economic mode)	5450 ANSI lumens
Focal length range	- mm
Lamp power	350 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	SDI
Noise level	44 dB
Noise level (economic mode)	39 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	910 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	690 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	660 mm
Width	510 mm
Height	263 mm
Weight	21000 g
Package depth	840 mm
Package width	650 mm
Package height	415 mm
Package weight	26500 g
