Barco PHWU-81B User Manual

13. Specifications
Pin No.
Spec
3
B(BLUE)/PB/CB
4
GND
5
GND
6
GND
7
GND
8
GND
9
DDC 5V
10
GND
11
GND
12
DDC Data
13
HD/CS
14 VD
15
DDC Clock
COMPUTER/COMPON ENT VIDEO DVI-D IN (HDCP) (DVI-D 24-pin)
1724
16
9
8
1
Image 13-4
Pin No.
Spec
1
TMDS DATA 2-
2
TMDS DATA 2+
3
TMDS DATA 2 Shield
4
-
5
-
6
DDC Clock
7
DDC Data
8
-
9
TMDS DATA 1-
10
TMDS DATA 1+
11
TMDS DATA 1 Shield
12
-
13
-
14 +5V Power
15
Ground (for +5V)
16 Hot plug detection
17
TMDS DATA 0-
18
TMDS DATA 0+
19
TMDS DATA 0 Shield
20
-
21
-
22
TMDS Clock Shield
23
TMDS Clock+
24
TMDS Clock-
R5905597 PHXX SERIES 20/05/2014 117

Barco PHWU-81B Specifications

General

Matrix size	0.67 \
Matrix type	DMD
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2800:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Projector brightness (economic mode)	5450 ANSI lumens
Focal length range	- mm
Lamp power	350 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	4000 h
Full HD	No
Supported graphics resolutions	1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
I/O ports	SDI
Noise level	44 dB
Noise level (economic mode)	39 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	910 W
Power consumption (standby)	0.3 W
Power consumption (economy mode)	690 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	30 - 90 %

Weight and Dimensions

Depth	660 mm
Width	510 mm
Height	263 mm
Weight	21000 g
Package depth	840 mm
Package width	650 mm
Package height	415 mm
Package weight	26500 g
