5. Advanced menu
Item
Setti ng
Function
CANCEL
OK
The pro cess to change the current resolution is canceled and the
SIGNA L menu is displayed .
HORIZ. POSITION
0-999
Use to adjust the horizontal position of the projected image.
VERT. POSITION
0-999
Use to adjust t he vertical position of the projected image.
FINE SYNC. 0-31 Use t o eliminate flickering or blur, if appears, viewing the projected
image.
TRACKING 0-9999 Use to elim inate vertical wide stripes, if appear s, viewing the projected
image.
COMPUTER INPUT AUTO The proper setting is automatically selected.
RGB Select this option when connecting the projector to high definition
video equipment having R, G, and B output terminals.
YCBCR/YPB PR Select this option when connecting the projector to a D VD player or
other device having Y, CB, and CR (or Y, PB, and PR) componen t
video output terminals.
OVER SCAN 100%-90% Use to adjust the display are a of projected image.
HOLD
OFF / ON
Use to adjust the image when flagging occurs near the top of the
screen.
ASPECT NORMAL For PHW U-81B:
Input video signal is displayed at the max height (1200 pixels) or m ax
width (1920 pixels) of the panel while its aspect ratio is m aintained.
→ When SCREEN is 16:9, the input video signal is displayed at the
max height (1080 pixels) or max width (1920 pixels) of the panel.
→ When SCREEN is 4:3, the input video signal is display ed a t the
max height (1200 pixels) or max width (1600 pixels) of the panel.
For PHW X-81B:
Input v ideo signal is displayed at the max height (800 pixels) or max
width (1280 pixels) of the panel while its aspect ratio is m aintained.
→ When SCREEN is 16:9, the input video signal is displayed at the
max height (720 pixels) or max width (12 80 pixels) of the panel.
→ When SCREEN is 4:3, the input video signal is d
isplayed at the
max height (800 pixels) or max width (10 66 pixels) of the panel.
For PHXG-91B:
Input v ideo signal is displayed at the max height (768 pixels) or max
width (1024 pixels) of the panel while its aspect ratio is m aintained.
→ When SCREEN is 16:9, the input video signal is displayed at the
max height (576 pixels) or max width (10 24 pixels) of the panel.
16:9
Regardless of the type of input signal, image is dis played at 16:9
aspect ratio. S elect to expand squeezed (or horizontally compressed)
images such as DVD images to 16:9.
NATIVE (for PHWU-
81B/PHWX -81B only)
Input v ideo signal is displayed at its o riginal pixel size.
FULL For PHWU-81B:
Select to project images in full size (1920 x 1200 pixels) irrespective of
type of input signal.
→ When SCR EEN is 16:9, images are displayed a t 192 0x1080 pixels.
→ W hen SCREEN is 4:3, im ages are displayed at 1600x1200 pixels.
For PHW X-81B:
Select to pro ject im ages in full size (1280 x 800 pixels) irrespective of
type of input signal.
→ W hen SCREEN is 16:9, images are displayed at 1280x720 pixels.
→ W hen SCREEN is 4:3, images are displayed at 1066x800 pixels.
For PHXG-91B:
Select to pro ject im ages in full size (1024 x 768 pixels) irrespective of
type of input signal.
50
R5905597 PHXX SERIES 20/05/2014
