122

BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION

DIRECTION OF

RECEIVING STATION

AT RIGHT ANGLES TO ANTENNA

Antenna

Earth (ground)

PRC-4090 Transceiver (P/N 4090-00-01)
