143

BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION

ABSOLUTE MINIMUM CLEARANCE

TOP VIEW

REAR OF VEHICLE

160mm

Important:

Considerations on the overall

height of the 2019 antenna once

tted should also be considered.
