BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION
Caution:- Whilst the 2019 automatic tuning mobile HF antenna is designed to with-
stand vibration to military specications on tyred vehicles, some mounting positions
on large prime-movers, particularly front mounted bull bars, are subject to vibration
that far exceeds this specication. Do not mount the 2019 antenna in positions such
as these as damage to the antenna may result.
ABSOLUTE MINIMUM CLEARANCE
TOP VIEW
160mm
BULL BAR
Important:
Please note that the mounting of a
2019 antenna on the front of a vehi-
cle may be considered illegal in some
areas / countries. Please check with
your local transport / vehicle authori-
ty prior to installation on the front of
your vehicle.
Considerations on the overall height
of the 2019 antenna once tted
should also be considered.
