7
BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INTRODUCTION
Mobile Conguration (front)
2
3
1
5
6
9
11
OFF
EMERG.
ON
Z
8
7
10
4
1
PRC-4090 HF SDR Transceiver (P/N 4090-00-01)
2
PRC-4090 System Docking Station (P/N 4090-05-00)
3
PRC-4090 Anti-vibration plate (P/N4090-05-07)
4
Earth stud
5
Whip antenna connection
6
50 Ohm antenna connection
7
LED status indicator
8
On/Off, Emergency and Zeroise switch
9
PRC-4090 Control Handset connector
10
H250 Handset connector
11
RF Connector (from 50 Ohm output)
