202

BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - APPENDICES

Control Handset

1. Handset Auxilliary Connector

PIN Signal

Reserved

USB Data Positive

USB Data Negative

+5 USB

Reserved

Ground

Handset Dock detection

Speaker Out Negative
