Basler GigE VISION CAMERAS User Manual

Specifications, Requirements, and Precautions AW00118303000
4 Basler racer GigE
Specification raL6144-16gm raL8192-12gm
Sensor Size
(Maximum Resolution)
6144 pixels 8192 pixels
Sensor Type Awaiba DR-6k-7
Monochrome Linear CMOS
Awaiba DR-8k-3.5
Monochrome Linear CMOS
Pixel Size 7µm x 7µm 3.5µm x 3.5µm
Max Line Rate 17 kHz 12 kHz
Min Line Rate No minimum when an external line trigger signal is used
100 Hz when an external line trigger signal is not used
Mono/Color Mono
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data
Formats
Mono 8
Mono 12
Mono 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bit
Synchronization Via external trigger signal, via software or free run
Exposure Control Programmable via the camera API
Camera Power
Requirements
+12 VDC (- 10 %) to +24 VDC (+ 5 %), < 1 % ripple, supplied via the camera’s 6-pin
connector
Max Power Consumption
(at 12 VDC)
< 4.5 W < 5.5 W
I/O Lines 3 input lines and 2 output lines
Lens Adapter Universal camera front, suitable for F-mount and M42 (×1.0 or ×0.75) adapter. Lens
adapter is not in the camera’s scope of delivery and must be ordered separately as
an accessory. See Section 1.4.4 on page 12 for information about selecting a
suitable lens adapter for your camera.
Size
(L x W x H)
36.2 mm x 56 mm x 62 mm (without lens adapter or connectors)
79.9 mm x 56 mm x 62 mm (with F-mount lens adapter and connectors)
49.5 mm x 56 mm x 62 mm (with M42-mount lens adapter and connectors)
Weight ~ 240 g (typical) without lens adapter
~ 330 g (typical) with F-mount lens adapter and connectors
~ 260 g (typical) with M42-mount lens adapter and connectors
Conformity CE, RoHS, FCC, UL (in preparation), GenICam, GigE Vision, IP30
Table 2: General Specifications - 6k and 8k Mono Cameras
